The Composite Coagulant Treatment of Printing and Dyeing Wastewater
Li Changbo, Xue Dong, Jiang Husheng, Zhang Honglin, Liu Dengchao
2014, 34 (2): 1-3. DOI:10.3696/j.issn.1672-6952.2014.02.001
Abstract ( ) PDF ( 2206KB ) ( ) 　　
Polyaluminium chloride (PAC) and PANDCD compound with coagulant was used to coagulate solute colloid or suspended particles in dye wastewater from a coloured socks factory. The influence of pH, coagulant dosing quantity, coagulation settling time on the coagulant performance are investigated and the coagulant performance was evaluated by the removal rate of COD and chroma. The results indicate that: compound coagulant in the treatment effect is better than single coagulant|the best operating conditions for compound coagulant to treat the dye wastewater was: compound coagulant dosage 10 mg/L, coagulation settling time 25 minutes, pH=7. In this case, the removal rate of chroma was 97.7%, removal rate of COD was 67.2%.
Related Articles | Metrics

Investigation of BSCN0.630%GDC Composite Cathode for ITSOFC
Zhang Leilei, Chang Ying, Huang Jinhua, Song Zhaoyuan, Fu Yidan, Liu Mo
2014, 34 (2): 4-8. DOI:10.3696/j.issn.1672-6952.2014.02.002
Abstract ( ) PDF ( 2430KB ) ( ) 　　
B a _{0. 6} S r _{0. 4} Co _{0. 9} N b _{0. 1} O _3 --δ (BSCN) perovskitetype oxide was prepared by the solid state reaction. The high temperature chemical compatibility between BSCN0.6 and G d _{0. 1} C e _{0. 9} O _{1. 9 -5}(GDC) were analyzed by XRD. XRD patterns indicate that a week solid solution between BSCN0.6 and GDC takes place after the BSCN0.6GDC composite material was calcined at high temperature. However, this solid solution does not show a negative effect on the performance of the cathode. The mixture of BSCN0.6 and GDC in a weight ratio of 70∶30 was used as SOFC composite cathode and the electrical property, thermal expansion behavior and electrochemical performance were investigated. The electrical conductivity was found to decrease with increasing GDC content|however, the thermal expansion coefficients (TEC) of BSCN0.630%GDC composite cathode decreased, which enhances the thermal match between the cathode and GDC electrolyte. With BSCN0.630%GDC as the electrode, the polarization resistance of a symmetrical cell BSCN0.630%GDC//GDC is only 0.047～0.012 Ω•cm2 in 700～800 ℃. Therefore, BSCN0.630%GDC composite material is a promising ITSOFC cathode.
Related Articles | Metrics

Treatment and Recovery of Iron and Steel Pickling Waste Water
Jiang Wei, Zhe Jianmei, Li Zhiguo, Li Wenfeng
2014, 34 (2): 9-11. DOI:10.3696/j.issn.1672-6952.2014.02.003
Abstract ( ) PDF ( 2788KB ) ( ) 　　
The source, the composition and the harm of iron and steel pickling waste water are introduced, and the state of art, the principle and the advantages/disadvantages on treating the iron and steel pickling waste water both domestic and abroad were analyzed. The present situation of acid recycling and metals recovery for the iron and steel pickling waste water is reviewed, and acid recycling methods including diffusion dialysis, membrane techniques, evaporation and spray roasting, and the metals recovery methods such as neutralization and precipitation, crystallization, ion exchange and so on are emphasized. These technology can achieve the acid recycling and metals recovery in order to make good use of resources.
Related Articles | Metrics

Comprehensive Evaluation and Retorting Technology  Selection of Tacheng Oil Shales in Xinjiang
Feng Chenchen， Cao Zubin， Han Dongyun，Li Dandong， Shi Yan， Liang Feixue
2014, 34 (2): 12-16. DOI:10.3696/j.issn.1672-6952.2014.02.004
Abstract ( ) PDF ( 1818KB ) ( ) 　　
The basic physicochemical characteristics of the Tacheng oil shales in Xinjiang province were investigated by a variety of experimental methods and a comprehensive evaluation was carried out. The properties of the oil shales such as oil yield, ash content, volatile component, calorific value, thermal intensity, rigidity and so on were investigated. The experimental result shows that the average oil yield is 7.32%, the average ash content is 65.94%, the average volatile component is 20.41%, the average calorific value is 4.55 MJ/kg, the thermal intensity and rigidity are both similar to the Fushun oil shales. In addition, the compositions of oil shales' ash were analyzed and demonstrated to be S i O2、 A l 2O3、 F e 2O3、 C a Oand MgO. Among them, SiO2 is main composition, followed by Al2O3 and Fe2O3. The comprehensive evaluation result shows that the basic physicochemical characteristics of the Tacheng oil shales in Xinjiang are close to that of Fushun oil shales, and the Fushun furnace retorting technology can suit the process of the Tacheng oil shale in Xinjiang.
Related Articles | Metrics

Effect of Moisture Treatment of Y Zeolite on Desulfurization of FCC Gasoline
Chai Yang, Liu Shu, Wang Jun, Lou Qinghai, Wang Xiaofei， Yu Tingyun
2014, 34 (2): 17-20. DOI:10.3696/j.issn.1672-6952.2014.02.005
Abstract ( ) PDF ( 1816KB ) ( ) 　　
With the Yzeolite as a carrier, nickel nitrate as the active component, a sorbent for FCC gasoline adsorption desulfurization is prepared. Treated with moist gas under the different temperature, the prepared adsorbent has a specific surface area 780 m2/g and aperture about 0.742 nm. The prepared sorbent are used for FCC gasoline desulfurization in the microreactor, the effects of space velocity on adsorbent activity of adsorption desulfurization are investigated. The results show that the adsorbent has good activity and its adsorption desulfurization rate reaches 89% when the active component content in the weight of Yzeolite is 15% and treated at 950 ℃, and space velocity is 0.5 h-1.
Related Articles | Metrics

OxidationExtraction Desulfurization by PyridiniumBased Ionic Liquid
Xing Dapeng， Li Xiuping， Li Chujia， Hu Yanan
2014, 34 (2): 21-23. DOI:10.3696/j.issn.1672-6952.2014.02.006
Abstract ( ) PDF ( 1824KB ) ( ) 　　
Base on the twostep method, ionic liquid \[BPy\]\[CF3SO3\] was synthesized from 1,4Butane sultone, ridine trifluoromethane sulfonic acid and py. Oxidationextraction desulfurization of model oil has been carried out with the ionic liquid as catalyst and 30% H2O2 as the oxidant. Desulfurization rate of model oil could reach to 94%, when treating 10 mL model oil with 0.6 g ionic liquid, 0.2 mL H2O2 at 50 ℃ for 30 min. After drying with rotary evaporator, the ionic liquid was regenerated for nextrun use, and the desulfurization rate could be still as high as 70% after recycling 5times.
Related Articles | Metrics

Preparation of Macroporous γ-Al2O3
Yang Pengchong, Han Yitong, Meng Xiuhong, Wang Haiyan, Zhao Weilin, Ji Haojie
2014, 34 (2): 24-28. DOI:10.3696/j.issn.1672-6952.2014.02.007
Abstract ( ) PDF ( 1854KB ) ( ) 　　
Alumina were prepared with aluminium sulfate as aluminium source, ammonium bicarbonate as precipitant, using substep aging method and L9 (34) orthogonal table. Factors inculding ammonium bicarbonate concentration, reaction temperature, pH and n(HCO-3)/n（Al3+） were studied. The alumina were characterized by the N2 physisorption and bulk density measurement, XRD and SEM as well. After orthogonal analysis, reaction temperature and pH have significant effect on textile properties of γAl2O3. Optimum preparation conditions were determined by macropore formation, and they were as follows: reaction temperature 75 ℃, pH 8.5, the concentration of ammonium bicarbonate 2 mol/L, n(HCO-3)/n（Al3+） ratio 075. Besides that, Y5 has big pore volume up to 2.02 mL/g, bimodal pore distribution and fibrous particles which have uniform size around 1 μm.
Related Articles | Metrics

Processing Conditions of Alkylation of  Thiophene with Laurylene over USY Zeolite
Jin Cong， Shen Jian
2014, 34 (2): 29-32. DOI:10.3696/j.issn.1672-6952.2014.02.008
Abstract ( ) PDF ( 1938KB ) ( ) 　　
atalytic alkylation of thiophene with laurylene by four kinds of Y zeolite catalyst was evaluated with gasoline as raw material in a small batch reactor. The experimental results show that USY1 molecular sieve shows highest alkylation activity and better selectivity than the other three catalysts. The optimum conditions of catalytic alkylation by USY1 molecular sieve was as follows: the reaction temperature 140 ℃, reaction time 2 h, catalyst to oil ratio 1∶10. Under above conditions, thiophene conversion rate could reach 88.17%, and high activity could be kept after recycling the catalyst 4 times. 
Related Articles | Metrics

Laboratory Study of the Composite OilWell Cement Early Strength Agent LL
Liang Lu, Li Lihua, Zhang Jinsheng, Wang Jing
2014, 34 (2): 33-36. DOI:10.3696/j.issn.1672-6952.2014.02.009
Abstract ( ) PDF ( 2164KB ) ( ) 　　
A chlorinefree composite as oilwell cement early strength agent named LL was developed. Combining organic acids A, alcohol amines B and nitrate compound C in a certain ratio, the compressive of cement stone in 6 h as the strength examining index can be designed in optimization test using the orthogonal method. The optimum formula determined by orthogonal was as follows: the weight of organic acids D is 1.0% based on cement，the weight of alcohols amines E is 0.04%，the weight of nitrates F is 4%. Under the optimum proportion, and the performance test of early strength agent LL was carried out after its addition of 2.5% in the cement. The ratio of the thickening time of early strength agent LL slurry to cement slurry is 0.436 less than 0.5, and the compressive strength of cement stone 6 h (39 ℃ and atmospheric pressure) is 11.0 MPa more than 4.0 MPa, they are all meeting the requirement of early strength agent industry standard SY/T5504.4—2008. And it has a good compatibility with the homemade retarders MAM, dispersants FASA and fluid loss AS.
Related Articles | Metrics

The Detection Technique of Surface Anti Corrosion  Layer for Gathering Pipeline in Liaohe Oilfields
Chen Zhaoxiong， Wu Ming， Xie Fei， Diao Zhaojin， Xu Jinmeng， Yang Chengquan， Zhang Shudong， Wang Anpeng
2014, 34 (2): 37-40. DOI:10.3696/j.issn.1672-6952.2014.02.010
Abstract ( ) PDF ( 1279KB ) ( ) 　　
By introducing PCM in the multifrequency principles and using DM produced by Radiodetection company, the article showed respectively the detection results of the anticorrosion layers from Shuwulian to first station, from Shuyilian to Shuwulian and from Shusilian to first station gathering pipelines in Shuguang oil production plant in Liaohe oilfield. The inferior and poor level of the three pipelines was accounted for 50.2%,51.8% and 42.9% respectively on all the anticorrosion layers. The detect results and the verification of suspected leaks were consistent. There were certain limitations when PCM was used only to detect underground pipes .If it was combinated with other detection means, the results would be more accurate.
Related Articles | Metrics

Numerical Simulation of ShellSide Fluid Flow and Heat  Transfer in Spherical Baffle Heat Exchanger
Guo Tu， Ma Guiyang， Huang Tenglong， Shi Long， Sun Hao
2014, 34 (2): 41-44. DOI:10.3696/j.issn.1672-6952.2014.02.011
Abstract ( ) PDF ( 2957KB ) ( ) 　　
In order to improve the performance of the conventional segmental baffle heat exchanger's heat transfer, a new type of baffle heat exchanger, namely a spherical baffle heat exchanger was proposed. Numerical analysis models for the spherical baffle heat exchanger which radius of curvature was 0.75D and conventional segmental baffle heat exchanger were established and the distribution of the shell side fluid flow field and the shell side pressure drop and the coefficient of heat transfer were obtained. The results indicate that under the conditions of the same structure parameters and the inlet flow velocity, shell side pressure drops cause by the spherical baffle heat exchanger were lower by8%～11% than those caused by the conventional segmental baffle, while the shell side heat transfer coefficient was decreased by 1%～5% compared with the spherical baffles. 
Related Articles | Metrics

Numerical Simulation of the Pressure Gradient Method to Position Pipeline Leak
Cao Yanlong， Wang Weimin， Ge Lei， Shi Junjie， Li Wuhua
2014, 34 (2): 45-48. DOI:10.3696/j.issn.1672-6952.2014.02.012
Abstract ( ) PDF ( 1895KB ) ( ) 　　
Because of the natural life of the pipeline and the impact of artificial factors, pipeline leakage accidents occur frequently. It is very important to detect pipeline leaks and determine the leak location to minimize damage and maintain the safe operation of the pipeline. Be aimed at the products pipeline leak, the CFD simulation software was used to simulate changes in the pipeline pressure. Once the pressure changed at the pipe end and beginning, the pipeline leak happened somewhere. Then under the pressure gradient changes of the pipeline end and beginning, the pressure gradient method was used to ultimately determine the leak location of the pipeline. 
Related Articles | Metrics

Numerical Simulation of Mixed Oil Characteristics in  Sequence Transportation on the Uphill and Downhill
Zhao Zhenzhi， Wang Weimin， Li Dan， Li Weiwei， Cao Yanlong， Liu Liyan
2014, 34 (2): 49-52.
Abstract ( ) PDF ( 3408KB ) ( ) 　　
Being aimed at the problem of contaminated oil in batch transportation of the same gasoline and diesel on different density condition during product oil flowing through the downhill and uphill, with the help of VOF model, the numerical calculation of threedimensional flow model was established. The influence of contaminated oil from different sequence，density，pipe range on boundary layer region was researched on the uphill and downhill road. The results showed that for uphill pipeline the length of the mixed oil of forward diesel was longer than forward gasoline，and the mixed oil volume of forward diesel was greater than forward gasoline. For downhill pipeline the length of the mixed oil of forward gasoline was longer than forward diesel and the mixed oil volume was greater than forward diesel. During forward the same gasoline and trailing diesel for different density diesel, the smaller density could help reduce mixed oil volume.
Related Articles | Metrics

Optimization of Development Methods for Heavy Oil Fractured Reservoir of CP Oilfield
Cao Lei， Liu Qian
2014, 34 (2): 53-56. DOI:10.3696/j.issn.1672-6952.2014.02.014
Abstract ( ) PDF ( 2918KB ) ( ) 　　
CP Oilfield is a dual medium of porosity glutenite anticline structure and is a x3suhshallow heavy oil reservoir. It was developed in natural depletion manner but the development effect was poor. Thermal development method is expected to get the better development effect according to the characteristics of crude oil that has the high viscosity, poor flow properties and buries in the creviced formation. According to the screening criteria of heavy oil development we analyzed and verified the result with reservoir numerical simulation method. The results show that depletion manner + huff and puff is the best development method. The ultimate recovery can be 52%. The reservoir numerical simulation method was farther applied to optimize the parameters and analyzed the sensitivity of the bottom hole dryness fraction. According to the optimized results of numerical simulation, the plan was implemented for one well in CP heavy oil reservoir. It has obtained a good effect in the case of low steam injection rate. This development mode provided a reference significance for similar oilfield.
Related Articles | Metrics

Analysis of Leakage Reasons for Joint of Tube of Header and  Weld Joints of Coil Tube on Coal Economizer
Ji Ming， Ao Feng， Hu Chuanshun， Tian Jingtao
2014, 34 (2): 57-60. DOI:10.3696/j.issn.1672-6952.2014.02.015
Abstract ( ) PDF ( 3435KB ) ( ) 　　
Through macroanalysis, chemical composition analysis, metallographic observation, and SEM, the leakage reasons for joint of tube of header and coil tube of coal economizer was analyzed. The results show that the alloy element compositions of welded tubes and conversion strength both met the standard of GB 5310—2008. The grains at fusion zone and overheated zone were coarse and even formed widmanstaten structure which made the performance of the zone weaken. Leakage from the joint of tube of header and coil tube of coal economizer resulted in the micro cracks in the weakened region of fusion and overheated zone under the thermal stress. Though throughwall crack was not formed after micro cracks initiation, micro cracks resulted in crevice corrosion and the crevice corrosion accelerated crack propagation from the inside outwords, and eventually caused the leakage.
Related Articles | Metrics

Wind Load Analysis of Coke Tower Based on ABAQUS
Meng Qingjuan， Guan Jinhua， Yang Yuman， Xie Tengteng， Sun Tie
2014, 34 (2): 61-64. DOI:10.3696/j.issn.1672-6952.2014.02.016
Abstract ( ) PDF ( 4521KB ) ( ) 　　
Wind load is a random load that can lead to the vibration of the coke tower. In order to research the influence on the strength of the coke tower by wind, ABAQUS was used to conduct the dynamic analysis of the wind load and the response of the structure during loading and unloading. The results indicate that, with the effect of wind, the maximal nodal displacement appeared at the top of the tower, which is 0.79 mm|while the maximal stress locate at the node around the skirt, the maximum is 3.26 MPa. Both of the displacement and stress could not cause the failure of the structure. During the loading and unloading, the structure engendered vibration along the loading direction. The vibration frequency was 10 Hz. Under the effect of external loads, it could easily cause the resonance of the structure, which could cause damages to the structure. Therefore it must be taken into consideration during the process of design and operation.
Related Articles | Metrics

Development of the AdjustableAngle Bend Drill Pipe
Zhang Guowei， Su Shanlin， Hao Rongming， Wang Xin
2014, 34 (2): 65-68. DOI:10.3696/j.issn.1672-6952.2014.02.017
Abstract ( ) PDF ( 2000KB ) ( ) 　　
In the processing of downhole accidents especially reservoir head accident, the fish head was not in the middle of the hole, and even attached to the variation of well radius was big. Therefore it was very difficult to implement common fishing method. On the site flexible elbow joints and bending drill pipes were generally to use to look for the fish. It would bend drill pipes many times, then cause waste and even safety accidents. According to this situation, the adjustableangle bend drill pipe was designed. It consisted of top connection, spline body, adjustable sleeve and lowercontact and so on. By adjusting spline body and adjustable sleeve, 0°～4°angle adjustment could be finished. The model machine of the adjustableangle bend drill pipe had been manufactured and applied to many oil wells. The results showed that it was available that the adjustableangle bend drill pipe was applied to fish the fishing head, which was easy to adjust the pipe on wellhead. The application was successful and 300 thousands could be saved per well.
Related Articles | Metrics

Current Status Analysis and Future Directions Prediction for Image SuperResolution Technique Based on Reconstructing Approach
Lu Ziwei， Wu Chengdong
2014, 34 (2): 69-73. DOI:10.3696/j.issn.1672-6952.2014.02.018
Abstract ( ) PDF ( 1638KB ) ( ) 　　
Image superresolution(SR) reconstruction technique is how to produce a clearly high resolution(HR) image from the information of one or several low resolution(LR) images, and it has been received increasing attention from the image processing community. In the paper, the fundamental principles and mathematical models of SR technology based on reconstruction were described firstly, and the history and stateofart of image SR reconstruction were stated briefly according to the classification between the frequency domain method and the space domain method. Secondly, advantages and defects of different methods were analyzed and summarized systematically. Finally, the further research directions for image SR technique of reconstructing based the approach were proposed.
Related Articles | Metrics

Autogeneration Technology and Application of  Variable Parameter Dialog Box Based on DCL
Lu Xin， Qin Yi, Zhao Na, Guan Cang
2014, 34 (2): 74-78. DOI:10.3696/j.issn.1672-6952.2014.02.019
Abstract ( ) PDF ( 1115KB ) ( ) 　　
The concept of variable parameter dialog box was proposed, focusing on the deficiencies of fixed parameter DCL dialog box in AutoCAD. The system automatically generated DCL files with the relative parameters according to the quantity of parameter that system actually required. And by the builtin VisualLISP in AutoCAD, the variable parameter dialog box was programmed. This defined and provided a new input method for AutoCAD user on the purpose of secondary development.
Related Articles | Metrics

An Empirical Study of an Influence of Auditor Size on Audit Quality
Qian Guangming， Chen Deyan
2014, 34 (2): 79-82. DOI:10.3696/j.issn.1672-6952.2014.02.020
Abstract ( ) PDF ( 974KB ) ( ) 　　
Taking listed companies issuing Ashares in the markets of Shanghai and Shenzhen in china as the research samples, an influence of auditor size on audit quality was studied by using multivariate statistical analysis. It indicated that a positive and weak relation between the accounting firm scale and the quality of auditing existed.
Related Articles | Metrics
