聚酯增塑剂在聚氯乙烯中的研究进展

doi:10.12422/j.issn.1006-396X.2025.06.008

摘要/Abstract

摘要：

聚氯乙烯（PVC）因机械性能优异、加工性好，被广泛应用于电缆、建材、人造革与包装领域。但是由于其刚性较大，通常需依赖增塑剂赋予柔韧性。系统概述了聚酯增塑剂对PVC性能调控的研究进展，重点探讨了结构设计、合成方法及其应用效果，通过对比分析分子结构、支化结构及端基功能化策略，阐明了聚酯增塑剂对PVC热稳定性、力学性能、迁移行为及加工流变性的影响机制。结果表明，合理设计聚酯分子结构可显著提升增塑效率与相容性，并降低增塑剂迁移与挥发的风险。生物基单体来源与绿色合成技术是聚酯增塑剂发展的关键方向，未来应聚焦多功能协同设计与规模化制备，以推动其在医疗、电缆与包装等领域的应用，实现高性能环保型PVC材料的可持续发展。

关键词: 聚酯增塑剂, 聚氯乙烯, 结构优化, 热稳定性, 迁移性

Abstract:

Polyvinyl chloride (PVC) is widely used in cables, building materials, artificial leather and packaging fields due to its excellent mechanical properties and good processability. However, because of its high rigidity, it needs to rely on plasticizers to endow flexibility. This paper systematically summarizes the research progress on the performance regulation of PVC by polyester plasticizers, with a focus on the structural design, synthesis methods and their application effects. Through comparative analysis of different molecular structures, branching structures and end group functionalization strategies, the influence mechanisms of polyester plasticizers on the thermal stability, mechanical properties, migration behavior and processing rheology of PVC are summarized. The results show that the rational design of the molecular structure of polyester can significantly improve the plasticizing efficiency and compatibility, and reduce the risk of plasticizer migration and volatilization. The conclusion holds that the source of bio?based monomers and green synthesis technology are the key directions for the development of polyester plasticizers. In the future, efforts should be focused on multi?functional collaborative design and large?scale preparation to promote their application in fields such as medical care, cables, and packaging, and achieve the sustainable development of high?performance and environmentally friendly PVC materials.

Key words: Polyester plasticizer, Polyvinyl chloride, Structural optimization, Thermal stability, Transferability

中图分类号:

TQ414

徐楠楠, 肖吉喆, 秦佳倩, 张娜, 高传慧. 聚酯增塑剂在聚氯乙烯中的研究进展[J]. 石油化工高等学校学报, 2025, 38(6): 65-73.

Nannan XU, Jizhe XIAO, Jiaqian QIN, Na ZHANG, Chuanhui GAO. Research Progress of Polyester Plasticizers in Polyvinyl Chloride[J]. Journal of Petrochemical Universities, 2025, 38(6): 65-73.

0
/ / 推荐

导出引用管理器 EndNote|Ris|BibTeX

链接本文: https://journal.lnpu.edu.cn/syhg/CN/10.12422/j.issn.1006-396X.2025.06.008

https://journal.lnpu.edu.cn/syhg/CN/Y2025/V38/I6/65

图/表 4

参考文献 52

[1]	LINDSTRÖM A，HAKKARAINEN M.Migration resistant polymeric plasticizer for poly（vinyl chloride）［J］.Journal of Applied Polymer Science，2007，104（4）：2458⁃2467.
[2]	HARMON P，OTTER R.A review of common non⁃ortho⁃phthalate plasticizers for use in food contact materials［J］.Food and Chemical Toxicology，2022，164：112984.
[3]	LJUNGBERG N，WESSLÉN B.Tributyl citrate oligomers as plasticizers for poly （lactic acid）：Thermo⁃mechanical film properties and aging［J］.Polymer，2003，44（25）：7679⁃7688.
[4]	张欣华，李泽天，王静，等.聚酯增塑剂增塑 PVC 最新研究进展［J］.石油化工高等学校学报，2016，29（4）：13⁃17.
	ZHANG X H，LI Z T，WANG J，et al.The newest research progresses of polyester plasticizer for PVC［J］.Journal of Petrochemical Universities，2016，29（4）：13⁃17.
[5]	LIU Y，ZHANG X，WANG Y，et al.Molecular design of high⁃performance polyester plasticizers for PVC：Influence of backbone flexibility and polarity［J］.Polymer，2021，230：124⁃128.
[6]	CHEN H，WANG J L.MOF⁃derived Co₃O₄⁃C@FeOOH as an efficient catalyst for catalytic ozonation of norfloxacin［J］.Journal of Hazardous Materials，2021，403：123697.
[7]	李天宇，龚静，王晨光.聚酯类增塑剂结构调控及其对PVC性能的影响［J］.合成材料老化与应用，2021，50（6）：15⁃19.
	LI T Y，GONG J，WANG C G.Structural regulation of polyester plasticizers and its influence on the properties of PVC［J］.Aging and Application of Synthetic Materials，2021，50（6）：15⁃19.
[8]	ZHANG Y，FENG X，ZHAO H，et al.Bio⁃based polyester plasticizers with enhanced migration resistance and thermal stability for flexible PVC［J］.ACS Sustainable Chemistry & Engineering，2020，8（12）：4716⁃4726.
[9]	WU X，CHEN L，LI D，et al.Synthesis and characterization of castor oil⁃based plasticizers for sustainable PVC［J］.Industrial Crops and Products，2021，162：113266.
[10]	JI S F，GAO C H，WANG H Z，et al.Application of a bio⁃based polyester plasticizer modified by hydrosilicon⁃hydrogenation reaction in soft PVC films［J］.Polymers for Advanced Technologies，2019，30（4）：1126⁃1134.
[11]	WANG X J，SONG M，LIU S T，et al.Analysis of phthalate plasticizer migration from PVDC packaging materials to food simulants using molecular dynamics simulations and artificial neural network［J］.Food Chemistry，2020，317：126465.
[12]	DANIELS P H.A brief overview of theories of PVC plasticization and methods used to evaluate PVC⁃plasticizer interaction［J］.Journal of Vinyl and Additive Technology，2009，15（4）：219⁃223.
[13]	李孝国，赵甲，费亚南，等.环保增塑剂环己烷1，2⁃二甲酸二异辛酯的合成［J］.石油化工高等学校学报，2013，26（5）：33⁃36.
	LI X G，ZHAO J，FEI Y N，et al.Synthesis of environmental plasticizer Di（2⁃ethylhexyl） 1，2⁃cyclohexane dicarboxylate［J］.Journal of Petrochemical Universities，2013，26（5）：33⁃36.
[14]	WANG M，LI B，WANG H，et al.Effects of branched structure on the compatibility and migration resistance of polyester plasticizers in PVC［J］.Polymer Testing，2020，85：106⁃114.
[15]	YIN B，AMINLASHGARI N，YANG X，et al.Glucose esters as biobased PVC plasticizers［J］.European Polymer Journal，2014（58）：34⁃40.
[16]	LIU Q，ZHANG Y，WANG Z，et al.Bio⁃based succinic acid⁃derived polyester plasticizers：Synthesis and migration resistance in PVC［J］.Journal of Applied Polymer Science，2021，138（31）：507⁃511.
[17]	WU X，CHEN L，LI D，et al.Castor oil⁃derived plasticizers for flexible PVC：Synthesis，performance and sustainability evaluation［J］.Industrial Crops and Products，2020，157：112⁃133.
[18]	王静，宋志强，何晓敏.微波辅助酯化法合成聚酯增塑剂的研究进展［J］.化工进展，2020，39（10）：4572⁃4579.
	WANG J，SONG Z Q，HE X M.Research progress on the synthesis of polyester plasticizers by microwave⁃assisted esterification［J］.Chemical Industry Progress，2020，39（10）：4572⁃4579.
[19]	GAO C H，ZHANG X H，SUN J W，et al.Poly（hexane succinate） plasticizer designed for poly（vinyl chloride） with a high efficiency，nontoxicity，and improved migration resistance［J］.Journal of Applied Polymer Science，2018，135（25）：46388.
[20]	GAO C H，WANG Y Q，GAO Y L，et al.Structure design，performance simulation and plasticizing properties of bio⁃based copolyesters plasticizer on PVC［J］.Journal of Polymers and the Environment，2022，30（11）：4651⁃4661.
[21]	ZHANG Y，ZHAO H，CHEN Y，et al.Biodegradable polyester plasticizers with hydrolysis⁃sensitive ester bonds for eco⁃friendly PVC materials［J］.Polymer Degradation and Stability，2022，201：109⁃115.
[22]	李雨彤，韩雪，胡笑.可降解聚酯增塑剂的分子结构设计与环境响应性能［J］.塑料科技，2023，51（4）：75⁃80.
	LI Y T，HAN X，HU X.Molecular structure design and environmental response performance of degradable polyester plasticizers［J］.Plastic technology，2023，51（4）：75⁃80.
[23]	SEARS J K，DARBY J R.The technology of plasticizers （SPE monographs）［M］.Etobicoke：John Wiley & Sons Inc，1982.
[24]	SKELLY P W，LI L，BRASLAU R.Internal plasticization of PVC［J］.Polymer Reviews，2022，62（3）：485⁃528.
[25]	王雷，胡笑，林睿.含环状二醇聚酯增塑剂对PVC热性能的调控作用［J］.合成材料老化与应用，2021，50（2）：22⁃27.
	WANG L，HU X，LIN Y.The regulatory effect of polyester plasticizers containing cyclic diols on the thermal properties of PVC［J］.Aging and Application of Synthetic Materials，2021，50（2）：22⁃27.
[26]	谢腾腾.2⁃甲基丁二酸类聚酯增塑剂的性能研究［D］.青岛：青岛科技大学，2014.
[27]	庄昌清，岳红，张慧军.分子模拟方法及模拟软件Materials Studio在高分子材料中的应用［J］.塑料，2010，39（4）：81⁃84.
	ZHUANG C Q，YUE H，ZHANG H J.Molecular simulation methods and Materials Studio applications to macromolecular material［J］.Plastics，2010，39（4）：81⁃84.
[28]	GAO C H，WANG B，HU Z F，et al.Effect of the molecular weight on the plasticization properties of poly（hexane succinate） in poly（vinyl chloride） blends［J］.Journal of Applied Polymer Science，2019，136（8）：47081.
[29]	JAGARLAPUDI S S，CROSS H S，DAS T，et al.Thermomechanical properties of nontoxic plasticizers for polyvinyl chloride predicted from molecular dynamics simulations［J］.ACS Applied Materials & Interfaces，2023，15（20）：24858⁃24867.
[30]	张妍，刘立，程远.端基调控对聚酯增塑剂相容性及迁移性的影响［J］.塑料科技，2022，50（1）：68⁃72.
	ZHANG Y，LIU L，CHENG Y.The influence of end group regulation on the compatibility and migration of polyester plasticizers［J］.Plastic Science and Technology，2022，50（1）：68⁃72.
[31]	ZHANG L，WANG Q，MA X，et al.Thermal behavior and migration resistance of novel polyester plasticizers［J］.Polymer Testing，2021，96：107⁃116.
[32]	张雪，胡晓斌.高分子聚酯增塑剂在PVC中的迁移行为研究［J］.高分子通报，2022（7）：65⁃72.
	ZHANG X，HU X B.Study on the migration behavior of polymer polyester plasticizers in PVC［J］.Polymer Bulletin，2022（7）：65⁃72.
[33]	彭思宇，宋俊.聚酯型增塑剂对PVC热力学性能的影响［J］.塑料工业，2021，49（4）：90⁃95.
	PENG S Y，SONG J.The influence of polyester⁃based plasticizers on the thermodynamic properties of PVC［J］.Plastics Industry，2021，49（4）：90⁃95.
[34]	ROSA D S，GUEDES C G F.Migration and toxicity of plasticizers in medical devices［J］.Biomed.Mater.Res，2020，108（9）：1825⁃1834.
[35]	ZHAO J，LI Y，XU T，et al.Influence of structure and molecular weight on plasticization of PVC with polyester plasticizers［J］.Applied Polymer.Science，2020，137（36）：489⁃494.
[36]	ZHANG H，LIU Q，CHEN R，et al.Effect of branched polyester plasticizers on thermomechanical properties of PVC［J］.Materials Today Communications，2021，26：108⁃119.
[37]	LU Y，LI Z，FANG Y.Study on rheological behavior of PVC with novel polyester plasticizers［J］.Polymer ⁃ Plastics Technology and Engineering，2022，61（12）：1250⁃1259.
[38]	王思琪，刘志宏，赵玉良.支化结构聚酯增塑剂的制备与性能研究［J］.塑料工业，2021，49（3）：48⁃53.
	WANG S Q，LIU Z H，ZHAO Y L.Preparation and performance research of branched polyester plasticizer［J］.Plastics Industry，2021，49（3）：48⁃53.
[39]	LI M，ZHANG H，LUO Q，et al.Structure–property relationships of flexible PVC with cyclic and linear polyester plasticizers［J］.Polymer Testing，2022，112：167⁃171.
[40]	胡浩，许晨阳，彭继新.聚酯增塑剂末端极性调控对PVC性能影响［J］.高分子通报，2020（9）：102⁃109.
	HU H，XU C Y，PENG J X.The influence of terminal polarity regulation of polyester plasticizers on the properties of PVC［J］.Polymer Bulletin，2020（9）：102⁃109.
[41]	RIAZ U，VASHIST A，AHMAD S A，et al.Compatibility and biodegradability studies of linseed oil epoxy and PVC blends［J］.Biomass and Bioenergy，2010，34（3）：396⁃401.
[42]	CHEN J，HUANG J，ZHANG L，et al.Synthesis of BHT⁃modified polyester plasticizers with antioxidant properties for PVC applications［J］.Polymer Degradation and Stability，2022，196：109⁃114.
[43]	JIA P Y，ZHANG M，HU L H，et al.Thermal degradation behavior and flame retardant mechanism of poly（vinyl chloride） plasticized with a soybean⁃oil⁃based plasticizer containing phosphaphenanthrene groups［J］.Polymer Degradation and Stability，2015，121：292⁃302.
[44]	WANG J，LIU Y，ZHANG X，et al.Biodegradable polyester plasticizers with enhanced plasticizing efficiency and hydrolytic degradability for PVC applications［J］.ACS Sustainable Chemistry & Engineering，2021，9（12）：4537⁃4546.
[45]	HALDEN R U.Plastics and health risks［J］.Annual Review of Public Health，2010，31：179⁃194.
[46]	TANG X，CHEN E，ZHANG Y，et al.Biodegradable polyester plasticizers：Design，synthesis，and degradation performance in PVC applications［J］.Journal of Environmental Chemical Engineering，2016，84（3）：343⁃354.
[47]	李洁，刘国文，王海峰.聚酯类增塑剂的毒理学评价与环保特性分析［J］.化工新型材料，2021，49（3）：112⁃116.
	LI J，LIU G W，WANG H F.Toxicological evaluation and environmental protection characteristics analysis of polyester plasticizers［J］.New Chemical Materials，2021，49（3）：112⁃116.
[48]	ZHANG X，JIANG Y，WANG W，et al.Bio⁃based monomers and green polymerization strategies for sustainable plasticizer development：A review［J］.ACS Sustainable Chemistry & Engineering，2023，11（8）：3145⁃3160.
[49]	吴全才，姜涛，陈新.环境友好磷系阻燃聚酯性能的研究［J］.石油化工高等学校学报，2007，20（2）：47⁃49.
	WU Q C，JIANG T，CHEN X.Performance of environmental friendly phosphorous flame⁃retardant polyester［J］.Journal of Petrochemical Universities，2007，20（2）：47⁃49.
[50]	CHOI W，CHUNG J W，KWAK S Y.Unentangled star⁃shape poly（ε⁃caprolactone）s as phthalate⁃free PVC plasticizers designed for non⁃toxicity and improved migration resistance［J］.ACS Applied Materials & Interfaces，2014，6（14）：11118⁃11128.
[51]	崔梦琪，张磊，刘清.可降解聚酯增塑剂在绿色PVC材料中的应用研究［J］.合成材料老化与应用，2020，49（4）：33⁃37.
	CUI M Q，ZHANG L，LIU Q.Research on the application of degradable polyester plasticizers in green PVC materials［J］.Aging and Application of Synthetic Materials，2020，49（4）：33⁃37.
[52]	王汇淄，丁煜，张迪，等.几种PVC用增塑剂的增塑与耐久性能研究［J］.石油化工高等学校学报，2018，31（4）：20⁃26.
	WANG H Z，DING Y，ZHANG D，et al.The plastic and durability performance of PVC plasticizer［J］.Journal of Petrochemical Universities，2018，31（4）：20⁃26.

阻燃剂类型	主要阻燃机制	特征描述	作用相
含磷型	生成聚磷酸或磷酸，促进炭层形成，阻断热源和可燃气体	阻燃效率高，炭层致密，热隔离性能优异	凝聚相
含氮型	分解释放惰性气体（N₂、NH₃），稀释燃烧气氛，吸热冷却	低毒、低烟，适用于环保阻燃设计，常与含磷体系协同使用	气相
含氯型	释放氯化氢（HCl）及氯自由基（Cl·），捕捉 ·OH和·H，终止链式燃烧反应	阻燃效率高但烟毒性大，逐渐被限制使用	气相
协同型	气⁃凝双相协同，形成炭层并释放惰性气体，构建稳定的阻燃屏障结构	多种机制协同效应，阻燃持久性强，适合高安全性PVC领域	气相+凝聚相

阻燃剂类型	主要阻燃机制	特征描述	作用相
含磷型	生成聚磷酸或磷酸，促进炭层形成，阻断热源和可燃气体	阻燃效率高，炭层致密，热隔离性能优异	凝聚相
含氮型	分解释放惰性气体（N₂、NH₃），稀释燃烧气氛，吸热冷却	低毒、低烟，适用于环保阻燃设计，常与含磷体系协同使用	气相
含氯型	释放氯化氢（HCl）及氯自由基（Cl·），捕捉 ·OH和·H，终止链式燃烧反应	阻燃效率高但烟毒性大，逐渐被限制使用	气相
协同型	气⁃凝双相协同，形成炭层并释放惰性气体，构建稳定的阻燃屏障结构	多种机制协同效应，阻燃持久性强，适合高安全性PVC领域	气相+凝聚相
